Shinybow SB-6135R Composite Video•Digital•Audio Receiver
Shinybow SB-6135R Composite Video•Digital•Audio Receiver
Input : 1x CAT5
Output : 1x Composite Video or Digital Audio and Stereo Audio (AR/AL)
Bảo hành: 12 tháng
Giá: Liên hệ
Lượt xem: 670
|
Mô tả chi tiết
Thông số kỹ thuật
|
1. |
Support Composite Video or Digital Audio(S/PDIF)/Stereo Audio over CAT5 Extension |
|
2. |
Input : 1x CAT5 |
|
3. |
Output : 1x Composite Video or Digital Audio and Stereo Audio |
|
4. |
Support HDTV Resolution: 480p / 720p / 1080i / 1080p |
|
5. |
Extending for long distance up to 100M (330ft) |
|
6. |
Wall mounted Ear Rack included |
|
Type of CAT5 |
Transmitter (TX) / Repeater + Receiver (RX) |
|
Type of Signal |
Composite Video or Digital Audio (PCM) / Stereo Audio via 3x RCA connectors |
|
Video Bandwidth |
Large Signal Bandwidth : 225Mhz, -3dB
Small Signal Bandwidth : 450Mhz, -3dB |
|
Output Balance error |
60dB @ 50Mhz |
|
High Isolation between Amplifier |
80dB @ 10Mhz |
|
Audio- In Impedance |
10 Ohms |
|
Audio Frequency Response |
20HZ to 20KHz, +/-1db |
|
Safety Approvals |
CE, FCC, VCCI |
|
Dimension (WxDxH) |
2.87" x 2.6" x1.15" (73mm x 66mm x 29.1mm) |
|
Power Supply |
DC12V / 1A Use Universal Switch Type 50/60Hz, 100~240VAC |
|
Weight |
0.17 kg / 0.37 lb |
